Square drive

25.4 mm (1")

Anvil length

163 mm (6-3/8")

Max fastening torque

3,150 N·m (2,323 ft.lbs.)

Fastening torque

Max/ Hard / Med. / Soft: 2,850 /1,600 / 1,000 / 600 N·m (2,100 /1,180 / 740 / 440 ft.lbs.)

Nut-busting torque

4,000 N·m (2,950 ft.lbs.)

Fastening capacities

Standard bolt: M27 - M45 (1-1/8 - 1-7/8")

High strength bolt: M20 - M33 (3/4 - 1-3/8")

No load speed

Max / Hard / Med. / Soft: 0 - 1,200 / 0 - 850 / 0 - 700 / 0 - 600 minˉ¹

Impacts per minute (IPM)

Max / Hard / Med. / Soft: 0 - 1,750 / 0 - 1,500 / 0 - 1,300 / 0 - 1,200

Sound pressure level

103 dB(A)

Sound power level

111 dB (A)

Noise K factor

3 dB(A)

Vibration level

33.4 m/s²

Dimensions(L x W x H)

: 570 x 135 x 297 mm (22-1/2 x 5-5/16 x 11-3/4")

Net weight

:12.0 - 12.9 kg (26.5 - 28.4 lbs.)
