1. 3-mode operation: Rotation only, Rotation & Hammering, Hammering only
2. 15.7m/s² of vibration
3. 800W* motor providing 3.0j** of hitting energy
4. One-touch sliding chuck for quick bit changes
Impacts per minute
: 0-4,500 minˉ¹
No load speed
: 0-1,500 minˉ¹
Continuous rating input
: 800 W
Capacity
: Concrete (w/ TCT bit): 26 mm (1")
: Concrete (w/ Core bit): 68 mm (2-11/16")
: Concrete (w/ Diamond core bit): 80 mm (3-1/8")
: Steel: 13 mm (1/2")
: Wood: 32 mm (1-1/4")
Impact energy
: 3.0 J
Vibration level (EN62841-2-6)
: Hammer drilling into concrete: 16.1 m/s²
: Chiselling: 14.2 m/s²
Vibration K factor (EN62841-2-6)
: Hammer drilling into concrete: 1.5 m/s²
: Chiselling: 1.5 m/s²
Sound pressure level (EN62841-2-6)
: 94 dB(A)
Sound power level (EN62841-2-6)
: 102 dB(A)
Noise K factor (EN62841-2-6)
: 3 dB(A)
Dimensions (L x W x H)
: 362 x 77 x 207 mm (14-1/4 x 3 x 8-1/8")
Net weight
: 2.9 - 3.4 kg (6.4 - 7.5 lbs.)
